Product Summary
The SKM180A020 is a Power MOSFET Module. The applications of the SKM180A020 include switched mode power supplies, DC servo and robot drives, DC choppers, UPS equipment, Plasma cutting, Not suitble for linear amplification.
Parametrics
SKM180A020 absolute maximum ratings: (1)VDS: 200V; (2)ID: 180A; (3)IDM: 540A; (4)VGS: ±20V; (5)TVJ(TSTG): -40 to 150(125)℃; (6)Visol: 2500V.
Features
SKM180A020 features: (1)N Channel, enhancement mode; (2)Avalanche characteristics; (3)Short internal connections avoid oscillations; (4)Isolated copper baseplates; (5)All electrical connections on top for easy busbaring; (6)Large clearances and creepage distances; (7)UL recognized, file no. E 63 532.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 SKM180A020 |
Other |
|
Data Sheet |
Negotiable |
|
||||
