Product Summary

The SKIIP25AC12T4V1 is a 3-phase bridge inverter.

Parametrics

SKIIP25AC12T4V1 absolute maximum ratings: (1)VCES: 1200V; (2)IC: 72A; (3)ICRM: 150A; (4)VGES: ±20V; (5)TPSC: 10μs; (6)It(rms): 100A; (7)Tvj: -40 to 175℃; (8)Tstg: -40 to 125℃; (9)Visol: 2500V.

Features

SKIIP25AC12T4V1 features: (1)Trench 4 IGBT’s; (2)Robust and soft freewheeling diodes in CAL technology; (3)Highly reliable spring contacts for electrical connections; (4)UL recognised file no.E63532.

Diagrams

SKIIP25AC12T4V1 block diagram
