Product Summary

The SKM50GA121D is an IGBT Module.

Parametrics

SKM50GA121D absolute maximum ratings: (1)VCES: 1200V; (2)IC: 50A; (3)VCEsat: 3.2V; (4)Ptot: 310W.

Features

SKM50GA121D features: (1)Rthjc: 0.40℃/W; (2)Rthch: 0.05℃/W; (3)case: D64.

Diagrams

SKM50GA121D block diagram
