Product Summary

The FST150Z2 is a Schottky PowerMod.

Parametrics

FST150Z2 absolute maximum ratings: (1)Average forward current, IF(AV): 150A; (2)Average forward current per leg, IF(av): 75A; (3)Maximum surge current, IFSM: 1000A; (4)Max repetitive peak reverse current, IR(ov): 2A; (5)Max peak forward voltage, VFM: 60V; (6)Max peak forward voltage per leg, VFM: 64V; (7)Max peak reverse current, IRM: 500mA; (8)Max peak reverse current per leg, IRM: 2mA.

Features

FST150Z2 features: (1)Schottky barrier rectifier; (2)Guard ring for reverse protection; (3)Low forward voltage; (4)VRRM 35 to 45V; (5)Electrically isolated base; (6)Reverse energy tested; (7)Cencer tap.

Diagrams

FST150Z2 block diagram
