FM2G100US60

FM2G100US60, Molding Type Module, 600V, 100A, 400W, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $50.00~64.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 30 :	64.00 / Piece
31 ~ 40 :	58.00 / Piece
41 ~ 50 :	50.00 / Piece

PartNumber:: FM2G100US60

Brand:: Fairchild Semiconductor - Fairchild | D/C: 10+

Availability:: Supply Ability: 1000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-28

From Other Seller

Part Number:FM2G100US60
US $50.00 - 64.00
FM2G100US60

US $30.00 - 40.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The FM2G100US60 is a Fairchild IGBT Power Module provides low conduction and switching losses as well as short circuit ruggedness. It’s designed for the applications such as motor control, UPS and general inverters where short-circuit ruggedness is required. The applications of the FM2G100US60 include AC & DC Motor Controls, General Purpose Inverters, Robotics, Servo Controls, UPS.

Parametrics

FM2G100US60 absolute maximum ratings: (1)VCES, Collector-Emitter Voltage: 600 V; (2)VGES, Gate-Emitter Voltage: ±20 V; (3)IC, Collector Current @ TC = 25℃: 100 A; (4)ICM (1), Pulsed Collector Current: 200 A; (5)IF, Diode Continuous Forward Current @ TC = 100℃: 100 A; (6)IFM, Diode Maximum Forward Current: 200 A; (7)TSC, Short Circuit Withstand Time @ TC = 100℃: 10 us; (8)PD, Maximum Power Dissipation @ TC = 25℃: 400 W; (9)TJ, Operating Junction Temperature: -40 to +150℃; (10)Tstg, Storage Temperature Range: -40 to +125℃; (11)Viso, Isolation Voltage @ AC 1minute: 2500 V; (12)Mounting Torque, Power Terminals Screw: M5 2.0 N.m; Mounting Screw: M5 2.0 N.m.

Features

FM2G100US60 features: (1)Short Circuit rated 10us @ TC = 100℃, VGE = 15V; (2)High Speed Switching; (3)Low Saturation Voltage: VCE(sat) = 2.2 V @ IC = 100A; (4)High Input Impedance; (5)Fast & Soft Anti-Parallel FWD.
