CM1200HA-24J

CM1200HA-24J, Single IGBTMOD H-Series Module, 1200V, 1200A, 5800W, MITSUBISHI

Rated 5 Rating 5 | reviews | Write a review

Price:: US $105.00~110.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 20 :	110.00 / Piece
25 ~ 35 :	108.00 / Piece
37 ~ 46 :	105.00 / Piece

PartNumber:: CM1200HA-24J

Brand:: MITSUBISHI - MITSUBISHI | D/C: 00+

Availability:: Supply Ability: 300/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-22

From Other Seller

Part Number:CM1200HA-24J
US $105.00 - 110.00
Quantity:

piece

Product Summary

The CM1200HA-24J is a Single IGBTMOD H-Series Module. The applications of the CM1200HA-24J include AC Motor Control, Motion/Servo Control, UPS, Welding Power Supplies, Laser Power Supplies.

Parametrics

CM1200HA-24J absolute maximum ratings: (1)Junction Temperature, Tj: -40 to 150℃; (2)Storage Temperature, Tstg: -40 to 125℃; (3)Collector-Emitter Voltage (G-E SHORT), VCES: 1200 Volts; (4)Gate-Emitter Voltage (C-E SHORT), VGES: ±20 Volts; (5)Collector Current (Tc = 25℃), IC: 1200 Amperes; (6)Peak Collector Current (Tj ≤ 150℃), ICM: 2400 Amperes; (7)Emitter Current (Tc = 25℃), IE: 1200 Amperes; (8)Peak Emitter Current, IEM: 2400 Amperes; (9)Maximum Collector Dissipation (Tc = 25℃), Pc: 5800 Watts; (10)Isolation Voltage (Main Terminal to Baseplate, AC 1 min.), Viso: 2500 Vrms.

Features

CM1200HA-24J features: (1)Low Drive Power; (2)Low VCE(sat); (3)Discrete Super-Fast Recovery (135ns) Free-Wheel Diode; (4)High Frequency Operation (20-25kHz); (5)Isolated Baseplate for Easy Heat Sinking.
