Product Summary
The UM300SHA-20 is a high performance trench P-ch MOSFET with extreme high cell density, which provides excellent RDSON and gate charge for most of the synchronous buck converter applications. The UM300SHA-20 meets the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved. The applications of the UM300SHA-20 include High Frequency Point-of-Load Synchronous Buck Converter for MB/NB/UMPC/VGA, Networking DC-DC Power System , Load Switch.
Parametrics
UM300SHA-20 absolute maximum ratings: (1)VDS, Drain-Source Voltage: -30V; (2)VGS, Gate-Source Voltage: ±20V; (3)ID@TC=25℃, Continuous Drain Current, VGS @ 10V1: -6A; (4)ID@TC=100℃, Continuous Drain Current, VGS @ 10V1: -4A; (5)IDM, Pulsed Drain Current: -12A; (6)EAS, Single Pulse Avalanche Energy: 59 mJ; (7)IAS, Avalanche Current: 19A; (8)PD@TC=25℃, Total Power Dissipation: 2.08 W; (9)TSTG, Storage Temperature Range: -55 to 150℃; (10)TJ, Operating Junction Temperature Range: -55 to 150℃.
Features
UM300SHA-20 features: (1)Advanced high cell density Trench technology; (2)Super Low Gate Charge; (3)Excellent CdV/dt effect decline; (4)100% EAS Guaranteed; (5)Green Device Available.
Diagrams
