Product Summary
The SSA250AA80 is a LED array using a Black Nylon 6 UL-94VO rated housing to mount six 3mm LEDs, mounted at 45 deg to a PCB. In any one batch the LEDs are lumenous intensity and matched.
Parametrics
SSA250AA80 absolute maximum ratings: (1)Forward Current: 30mA; (2)Power Dissipation: 100mW; (3)Reverse Current @ 5V: 10mA; (4)Operating Temperature: -40 to +85℃; (5)Storage Temperature: -40 to 100℃; (6)Lead Soldering Temperature for 5sec (2.0mm from Body): 260℃.
Features
SSA250AA80 features: (1)Accurate alignment of LEDs; (2)8mm Pitch; (3)45Deg Viewing Angle; (4)Low current and high brightness available.
Diagrams
