Product Summary
The SKM300GB174D is a Low Loss IGBT Module. The applications of the SKM300GB174D include AC inverter drives on mains 575-750Vac, DC bus voltage 750-1200VAC, public transport, switching(not for linear use).
Parametrics
SKM300GB174D absolute maximum ratings: (1)VCES: 1700 V; (2)IC @ Tcase=25℃: 320 A; (3)ICRM: 400A; (4)Ptot @ Tcase=25℃: 1400 W; (5)Vges: ±20V; (6)TVJ,(TSTG): -40 to 150(125)℃; (7)Visol: 3400V.
Features
SKM300GB174D features: (1)N channel, homogeneous Silicon structure(NPT-Non punch-trough IGBT); (2)Low inductance case; (3)High short circuit capability, self limiting; (4)Fast&soft inverse CAL diodes; (5)Without hard mould; (6)Isolated copper baseplate using DCB direct copper bonding; (7)Large clearance (13mm) and creepage distances (20mm).
Diagrams
