Product Summary

The 7MBI75SA-060B is an IGBT module.

Parametrics

7MBI75SA-060B absolute maximum ratings: (1)collector-emitter voltage: 600V; (2)gate-emitter voltage: ±20V; (3)collector current: 75A; (4)collector power dissipation: 320W; (5)gate-emitter voltage: ±20V.

Features

7MBI75SA-060B features: (1)including brake chopper; (2)square RBSOA; (3)low saturation voltage; (4)overcurrent limiting function.

Diagrams

7MBI75SA-060B block diagram
