Product Summary

The SKM195GB124DN is a Low Loss IGBT Module. The applications of the SKM195GB124DN include switching (not for linear use), switched mode power supplies, DC servo and robot drives, inverters, DC choppers, AC motor speed control, UPS uniterruptable power supplies, general power switching applications, electronic (also portable) welders.

Parametrics

SKM195GB124DN absolute maximum ratings: (1)Tj= 25℃, VCES: 1200V; (2)Tj= 150℃, Tcase= 25℃, Ic: 260A; Tcase= 80℃, Ic: 180A; (3)ICRM= 2×1Cnom, ICRM: 520A; (4)VGES: ±20V; (5)VCC= 1200V; VGE≤ 20V; Tj= 125℃, VCES＜1700V, tpsc: 10μs.

Features

SKM195GB124DN features: (1)N channel, homogeneous Si; (2)low inductance case; (3)short tail current with low temperature dependence; (4)high short circuit capability, self limiting to 6Icnom; (5)fast & soft inverse CAL diodes; (6)isolated copper baseplate using DCB direct copper bonding technology; (7)large clearance and creepage distance.

Diagrams

SKM195GB124DN block diagram
