Product Summary
The SKM150GB128D is a SPT IGBT Module. The applications of it are AC inverter drives, UPS, electronic welders at fsw up to 20kHz.
Parametrics
SKM150GB128D absolute maximum ratings: (1)VCES: 1200V; (2)IC: 200A; (3)ICRM: 200A; (4)IFRM: 200V; (5)Tvj: -40℃ to +150℃; (6)Tstg: -40℃ to +125℃; (7)Visol: 4000V.
Features
SKM150GB128D features: (1)homogeneous Si; (2)SPT=soft-punch-through technology; (3)VCEsat with positive temperature coefficient; (4)high short circuit capability, self limiting to 6*IC.
Diagrams
