Product Summary

The SKIIP37AC126V2 is a 3-phase bridge inverter. The applications of the SKIIP37AC126V2 include inverter up to 35kVA, typical motor power 18.5kW.

Parametrics

SKIIP37AC126V2 absolute maximum ratings: (1)VCES: 1200V; (2)IC: 97A; (3)ICRM: 150A; (4)VGES: ±20V; (5)Tj: -40 to 150℃; (6)IF: 90A; (7)IFRM: 150A; (8)ItRMS: 160A; (9)Tstg: -40 to 125℃; (10)Visol: 2500V.

Features

SKIIP37AC126V2 features: (1)Fast trench IGBTs; (2)Robust and soft freewheeling diodes in CAL technology; (3)Highly reliable spring contacts for electrical connections; (4)UL recognised file no.E63532.

Diagrams

SKIIP37AC126V2 block diagram
