Product Summary

The 7MBR100U2BC60 is an IGBT module. The applications of the 7MBR100U2BC60 include Inverter for Motoe Drive, AC and DC Servo Drive Amplifier, Uninterruptible Power Supply.

Parametrics

7MBR100U2BC60 absolute maximum ratings: (1)Inverter, Collector-Emitter voltage, VCES: 600V; (2)Inverter, Gate-Emitter voltage, VGES: ±20V; (3)Inverter, Collector current, IC: 100A; ICP: 200A; -IC: 100A; -ICP: 200A; (4)Inverter, Collector power disspation, PC: 378W; (5)Brake, Collector-Emitter voltage, VCES: 600V; (6)Brake, Gate-Emitter voltage, VGES: ±20V; (7)Brake, Collector current, IC: 50A; ICP: 100A; (8)Brake, Collector power disspation, PC: 187W; (9)Brake, Repetitive peak reverse voltage, VRRM: 600V.

Features

7MBR100U2BC60 features: (1)Low VCE(sat); (2)Compact Package; (3)P.C. Board Mount Module; (4)Converter Diode Bridge Dynamic Brake Circuit.

Diagrams

7MBR100U2BC60 block diagram
