Product Summary

The G6C-2114P-US-5V is a kind of Miniature High Capacity Relay.

Parametrics

G6C-2114P-US-5V absolute maximum ratings: (1)Contact resistance: 30 mΩ max.; (2)Operate (set) time: 10 ms max.; (3)Release (reset) time: 10 ms max.; (4)Insulation resistance Between coil and contacts: 1,000 mΩ min.; (5)Insulation resistance Between contacts of the same polarity: 1,000 mΩ min.; (6)Failure rate (P level) (reference value): 10 mA at 5 VDC; (7)Ambient operating temperature: -25°C to 70°C (with no icing or condensation).

Features

G6C-2114P-US-5V features: (1)SPST-NO 10A and SPST-NO + SPST-NC 8A for power switching and output that satisfy the needs for space-saving; (2)Small High-capacity Relays Compact: 20x15x10 mm (LxWxH); (3)Low power consumption: 200 mW; (4)Ultrasonically cleanable models is available; (5)Exclusive P6C model for sockets is now available.

Diagrams

G6C-2114P-US-5V circuit diagram
