Product Summary

The N87C196MC is a 16-bit microcontroller designed primarily to control 3 phase AC induction and DC brushless motors. The N87C196MC is based on Intel’s MCS 96 16-bit microcontroller architecture and is manufactured with Intel’s CHMOS process. The N87C196MC has a three phase waveform generator specifically designed for use in "Inverter" motor control applications. This peripheral allows for pulse width modulation, three phase sine wave generation with minimal CPU intervention. It generates 3 complementary non-overlapping PWM pulses with resolutions of 0.125μs (edge trigger) or 0.250μs (centered).

Parametrics

N87C196MC absolute maximum ratings: (1)Ambient Temperature Under Bias: -40℃ to +85℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage from EA or VPP to VSS or ANGND: +13.0V; (4)Voltage on VPP or EQ to VSS or ANGND: -0.5V to 13.0V; (5)Voltage on Any Other Pin to VSS or ANGND: -0.5V to +7.0V; (6)Power Dissipation: 1.5W.

Features

N87C196MC features: (1)High-Performance CHMOS 16-Bit CPU; (2)16 Kbytes of On-Chip OTPROM/Factory-Programmed OTPROM; (3)488 bytes of On-Chip Register RAM; (4)Register to Register Architecture; (5)Up to 53 I/O Lines; (6)Peripheral Transaction Server (PTS) with 11 Prioritized Sources; (7)Event Processor Array (EPA); (8)4 High Speed Capture/Compare Modules; (9)4 High Speed Compare Modules; (10)Extended Temperature Standard; (11)Two 16-Bit Timers with Quadrature Decoder Input; (12)3-Phase Complementary Waveform Generator; (13)13 Channel 8/10-Bit A/D with Sample/Hold with Zero Offset Adjustment H/W; (14)14 Prioritized Interrupt Sources; (15)Flexible 8-/16-Bit External Bus; (16)1.75μs 16 x 16 Multiply; (17)3μs 32/16 Divide; (18)Idle and Power Down Modes.
