Product Summary
The F5033 is a power MOSFET.
Parametrics
F5033 absolute maximum ratings: (1)drain source voltage, Vdss: 4.0V; (2)gate source voltage, Vgss: DC-0.3 to 7.0V; (3)continuous drain current, Io: 1A; (4)maximum power dissipation, Pd: 1.5W; (5)operating junction temperature, Tj: 150℃; (6)storage temperature range, Tstg: -55 to 150℃.
Features
F5033 features: (1)drain source clamp voltagte, VDSS: 4.0 to 6.0V; (2)gate threshold votlage, VGS: 2.8V; (3)operation gate voltage, VOS: 3.5 to 7.0V; (4)zero gate voltage drain current, IDSS: 1.0mA.
Diagrams
![]() |
