Product Summary
The ADA4627-1ARZ is a wide bandwidth precision amplifier featuring low noise, very low offset, drift, and bias current. Operation is specified from ±5 V to ±15 V dual supply. The ADA4627-1ARZ provides benefits previously found in few amplifiers. This amplifier combines the best specifications of precision dc and high speed ac op amps. The applications of the ADA4627-1ARZ are (1)High impedance sensors; (2)Photo diode amplifier; (3)Precision instrumentation; (4)Phase-locked loop filters; (5)High end, professional audio; (6)DAC output amplifier; (7)ATE; (8)Medical.
Parametrics
ADA4627-1ARZ absolute maximum ratings: (1)Supply Voltage: 36 V; (2)Input Voltage Range: (V-) - 0.3 V to (V+) + 0.3 V; (3)Input Current: ±10 mA; (4)Differential Input Voltage: ±VSY; (5)Output Short-Circuit Duration to GND: Indefinite; (6)Storage Temperature Range: -65℃ to +150℃; (7)Operating Temperature Range: -40℃ to +125℃; (8)Junction Temperature Range: -65℃ to +150℃; (9)Lead Temperature (Soldering, 60 sec): 300℃; (10)ESD Human Body Model: 2.5 kV.
Features
ADA4627-1ARZ features: (1)Low offset voltage: 200 μV maximum; (2)Offset drift: 1 uV/℃ typical; (3)Very low input bias current: 5 pA maximum; (4)Extended temperature range: -40 to +125℃; (5)±5 V to ±15 V dual-supply; (6)Guaranteed GBW: 16 MHz; (7)Voltage noise: 6.1 nV/√Hz at 1 kHz; (8)High slew rate: 60 V/us; (9)High gain: 120 dB typical; (10)High CMRR: 116 dB typical; (11)High PSRR: 112 dB typical; (12)Low supply current: 7.5 mA maximum.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADA4627-1ARZ |
|
IC OPAMP JFET 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
ADA4627-1ARZ-R7 |
|
IC OPAMP JFET 19MHZ LN 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
ADA4627-1ARZ-RL |
|
IC OPAMP JFET 19MHZ LN 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
