Product Summary

The E5EK-AA2 is a digital controller.

Parametrics

E5EK-AA2 absolute maximum ratings: (1)Supply voltage: AC100–240V~, 50/60 Hz or AC/DC24V~, 50/60 Hz; (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Auxiliary output: SPST-NO, 3 A at 250 VAC (resistive load); (4)Control method: ON/OFF or advanced PID control (with auto-tuning); (5)Setting method: Digital setting using front panel keys; (6)Indication method: 7-segment digital display and LEDs; (7)Potentiometer: 100 Ω to 2.5 kΩ; (8)Transmission output: 4 to 20 mA, permissible load impedance: 600 W max., resolution: approx. 2,600.

Features

E5EK-AA2 features: (1)Modular structure, one-stock type; (2)High-accuracy: 100 ms sampling (for analog input); (3)Advanced tuning which includes fuzzy self-tuning; (4)Conforms to international EMC and safety standards; (5)IP66/NEMA4 (indoor use) front face; (6)Remote set point; (7)Serial communications (RS-232C, RS-422 and RS-485) and transfer output (4 to 20 mA); (8)Position-proportional control model; (9)Heat/Cool control; (10)AC/DC24V types are also available.

Diagrams

E5EK-AA2 dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
E5EK-AA2-500
E5EK-AA2-500

Omron Industrial

Controllers 1/8 DIN 100-240VAC Digital field config

Data Sheet

Negotiable
E5EK-AA2-500 AC/DC24
E5EK-AA2-500 AC/DC24

Omron Industrial

Controllers 1/8 DIN 240VAC STANDARD MODEL

Data Sheet

Negotiable
E5EK-AA2-DRT AC/DC24
E5EK-AA2-DRT AC/DC24

Omron Industrial

Controllers 1/8DIN 24VAC/VDC Process Controller

Data Sheet

Negotiable
E5EK-AA2-DRT AC100-240
E5EK-AA2-DRT AC100-240

Omron Industrial

Controllers PROCESS CONTROLLER

Data Sheet

Negotiable
E5EK-AA2B
E5EK-AA2B

Omron Industrial

Controllers TEMPERATURE CONTROLL ER 1/4 DIN

Data Sheet

Negotiable
E5EK-AA2-DRT-500 AC/DC24
E5EK-AA2-DRT-500 AC/DC24


CONTROLR PROCESS 24V 1/8DIN

Data Sheet

0-1: $336.22
E5EK-AA2-DRT-500-AC/DC24
E5EK-AA2-DRT-500-AC/DC24

Omron Industrial

Controllers DEVICENET AC/DC 24V

Data Sheet

Negotiable
E5EK-AA2-DRT-500-AC100-240
E5EK-AA2-DRT-500-AC100-240

Omron Industrial

Controllers DEVICENET 100-240VAC

Data Sheet

Negotiable
