Product Summary
The E5CK-QQ1B is an advanced, compact digital controller. And it can be used in (1)Electric furnaces; (2)Thermostats; (3)Food-processing machinery; (4)Drying machinery; (5)Molding equipment; (6)Heating devices; (7)Other applications requiring high-precision temperature control.
Parametrics
E5CK-QQ1B absolute maximum ratings: (1)Supply voltage: AC100 to 240V, 50/60 Hz; (2)Power consumption: 15 VA; (3)Operating voltage range: 85% to 110% of rated supply voltage; (4)Control output: According to Output Unit; (5)Auxiliary output: SPST-NO, 1 A at 250 VAC (resistive load); (6)Control method: ON/OFF or 2-PID control (with auto-tuning); (7)Setting method: Digital setting using front panel keys; (8)Indication method: 7-segment digital display and LEDs; (9)Other functions: According to Option Unit.
Features
E5CK-QQ1B features: (1)IP66/NEMA4 (indoor use) front face; (2)Modular structure, one-stock type; (3)Heating/cooling control; (4)Serial communications (RS-232C and RS-485); (5)Temperature and analog inputs; (6)High-accuracy: 100 ms sampling (for analog input); (7)Advanced tuning which includes fuzzy self-tuning; (8)Conforms to international EMC and safety standards; (9)AC/DC24V types are also available.
Diagrams
