Product Summary
The E5EN-C3TD-N is a basic-type digital temperature controller. And it can be used in (1)Electric furnaces; (2)Thermostats; (3)Food-processing machinery; (4)Drying machinery; (5)Molding equipment; (6)Heating devices; (7)Other applications requiring high-precision temperature control.
Parametrics
E5EN-C3TD-N absolute maximum ratings: (1)Operating voltage range: 85% to 110% of rated supply voltage; (2)Input Thermocouple: Current input: 150 Ω max., Voltage input: 1 MΩ min. (Use a 1:1 connection when connecting the ES2-HB.); (3)Auxiliary output: Relay output: SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations, minimum applicable load: 5 V, 10 mA; (4)Control method: ON/OFF control or 2-PID control (with auto-tuning); (5)Setting method: Digital setting using front panel keys; (6)Indication method: 7-segment digital display and LEDs; (7)Enclosure ratings: Conforms to IEC IP66 and NEMA4 (Indoor use); (8)Ambient temperature: Operating: -10°C to 55°C (with no icing or condensation).
Features
E5EN-C3TD-N absolute maximum ratings: (1)Operating voltage range: 85% to 110% of rated supply voltage; (2)Input Thermocouple: Current input: 150 Ω max., Voltage input: 1 MΩ min. (Use a 1:1 connection when connecting the ES2-HB.); (3)Auxiliary output: Relay output: SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations, minimum applicable load: 5 V, 10 mA; (4)Control method: ON/OFF control or 2-PID control (with auto-tuning); (5)Setting method: Digital setting using front panel keys; (6)Indication method: 7-segment digital display and LEDs; (7)Enclosure ratings: Conforms to IEC IP66 and NEMA4 (Indoor use); (8)Ambient temperature: Operating: -10°C to 55°C (with no icing or condensation); (9)Ambient humidity Operating: 25% to 85%.
