Product Summary

The S82K-03012 is an ultimate DIN-track-mounting power supplier.

Parametrics

S82K-03012 absolute maximum ratings: (1)Voltage adjustment range: ±10% (V.ADJ); (2)Ripple: 2% (p-p) max.; (3)Load variation influence: 1.5% max. (0 to 100% load); (4)Temperature variation: 0.05%/°C max.; (5)Startup time 200 ms max.; (6)Hold time: 20 ms min.; (7)Screw tightening torque 0.74 N • m max..

Features

S82K-03012 features: (1)Wide power range: 3 to 240 W; (2)Wide AC input voltage range: 100 to 240 V on one body.; (3)Undervoltage alarm function (indicator) incorporated as standard (With the 240-W models, applicable only to the T models.) 90 and 100-W models standardized with the alarm output; (4)Output/input terminal parts separated on body upper/bottom side, respectively, for safe and smart wiring; (5)Multiple pairs of output terminals; Three pairs for 90, 100, and 240-W models, Two pairs for 30 and 50-W models; (6)Finger-safe terminal block with cover according to VDE0106/P100; (7)Conforms to the stringent EN50081-1 standard for universal use in any environment subject to EMI conditions (except for 240-W models) in addition to EN50082-2 conformity for use at any EMS environment; (8)DC output ports comply to EN55022 class A, thus ensuring use in any environment subject to EMI with recommended external filters (3- to 100-W models); (9)Meets EN61000-3-2 (limits for harmonic current emissions) with PFC on 90, 100, and 240-W models; (10)Parallel running operation (100 and 240-W models); (11)Class 2 approved (except for 240-W models and 7.5-W dual output models); (12)Approvals of various international safety standards for industrial control equipment and industrial computing systems (ITE/TE), in addition to other important approvals; (13)Six-language instruction manual provided.
