Product Summary
The SKM400GA173D is an IGBT module. Its applications include AC inverter drives on mains, 575-750 Vac, DC bus voltage 750-1200 Vdc, Public transport, Swithcing (not for linear use).
Parametrics
SKM400GA173D absolute maximum ratings: (1)VCES: 1700V; (2)VCGR: 1700V; (3)IC: 440/300A; (4)ICM: 880/600A; (5)VGES: ±20V; (6)Ptot: 2500W; (7)Vsiol: 4000V.
Features
SKM400GA173D features: (1)MOS input(voltage controlled); (2)N channel,Homgeneous Si; (3)Low inductance case; (4)Very low tail current with low temperature dependence; (5)Hight short circuit capability, self limiting to 6x 1cnom; (6)Latch-up free; (7)Fast & soft inverse CAL diodes; (8)lsolated copper baseplate using DBC Direct Copper Bonding Technology; (9)Large clearance(13mm) and creepage distances(20mm).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 SKM400GA173D |
Other |
|
Data Sheet |
Negotiable |
|
||||
