Product Summary
The SKIIP942GB120-3D is a 3-Phase Bridge Rectifier+braking chopper+3-phase bridge inverter.
Parametrics
SKIIP942GB120-3D absolute maximum ratings: (1)IGBT-Inverter: VCES: 1200V; VCC, operating DC link voltage: 900V; VGES: ±20V; IC, ts=25(70)℃: 900(675)A; (2)Diode-Inverter: IF=-IC, Ts = (25)70 ℃: 900(675) A; IFSM, tp = 10 ms: 64800A; I2t(diode), Diode, Tj=150℃, 10ms: 210 kA2s; (3)Tj(Tstg): -40 to 150(125)℃; (4)Viso, AC, 1min: 3000V.
Features
SKIIP942GB120-3D features: (1)SKiip technology inside; (2)SPT (soft punch trough) IGBTs; (3)CAL diode technology; (4)Integrated current sensor; (5)Integrated temperature sensor; (6)Integrated heat sink; (7)IEC 60721-3-3 (humidity) class 3K3/IE32; (8)IEC 60068-1(climate) 40/125/56; (9)UL recognized file no.E65532.
Diagrams
