Product Summary

The SKIIP26AC12T4V1 is a 3-phase bridge inverter.

Parametrics

SKIIP26AC12T4V1 absolute maximum ratings: (1)Vces: 1200V; (2)Ic: 96V; (3)Icrm: 225A; (4)Vges: ±20V; (5)Tpsc: 10μs; (6)If: 83A; (7)Ifrm: 225A; (8)Ifsm: 429A.

Features

SKIIP26AC12T4V1 features: (1)Trench 4 IGBTs; (2)Robust and soft freewheeling diodes in CAL technology; (3)Highly reliable spring contacts for electrical connections; (4)UL recognised fil NO.E63532.

Diagrams

SKIIP26AC12T4V1 block diagram
