Product Summary
The SEMIX553GB128DS is a SPT IGBT module. The applications of the SEMIX553GB128DS include AC inverter drives; UPS; Electronic welders at fsw up to 20kHz.
Parametrics
SEMIX553GB128DS absolute maximum ratings: (1)VCES: 1200V; (2)IC, TC=25(80)℃: 540(380)A; (3)ICRM, tp=1ms: 600A; (4)VGES: ±20V; (5)Tvj, Tstg, TOPERATION≤Tstg: -40 to +150(125)℃; (6)Visol, AC, 1MIN.: 4000V.
Features
SEMIX553GB128DS features: (1)Homogeneous Si; (2)SPT=Soft punch through technology; (3)VCEsat with positive temperature coefficient; (4)High short circuit capability.
Diagrams
