QM200DY-24

QM200DY-24, high power switching use insulated type module, 1200V, 200A, 1980W, MITSUBISHI

Rated 5 Rating 5 | reviews | Write a review

Price:: US $100.00~123.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 30 :	123.00 / Piece
31 ~ 60 :	115.00 / Piece
61 ~ 90 :	100.00 / Piece

PartNumber:: QM200DY-24

Brand:: MITSUBISHI - MITSUBISHI | D/C: 09+

Availability:: Supply Ability: 500/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-26

From Other Seller

Part Number:QM200DY-24
US $100.00 - 123.00
Quantity:

piece

Product Summary

The QM200DY-24 is a high power switching use insulated type module. The applications of the QM200DY-24 include AC motor controllers, UPS, CVCF, Inverters, DC motor controllers, NC equipment, Welders.

Parametrics

QM200DY-24 absolute maximum ratings: (1)Collector-emitter voltage, VCEX (SUS): 1200V; (2)Collector-emitter voltage, VCEX: 1200V; (3)Collector-base voltage, VCBO: 1200V; (4)Emitter-base voltage, VEBO: 7V; (5)Collector current, IC: 200A; (6)Collector reverse current, -IC: 200A; (7)Collector dissipation, PC: 1980W; (8)Base current, IB: 10A; (9)Surge collector reverse current (forward diode current), -ICSM: 2000A; (10)Junction temperature, Tj: -40 to +150℃; (11)Storage temperature, Tstg: -40 to +125℃; (12)Isolation voltage, Viso: 2500V.

Features

QM200DY-24 features: (1)IC Collector current: 200A; (2)VCEX Collector-emitter voltage: 1200V; (3)hFE DC current gain: 750; (4)Insulated Type; (5)UL Recognized, Yellow Card No. E80276 (N), File No. E80271.
