Product Summary

The P540A06 is a 4.9-5.9GHz Band Chip Multilayer Band Pass Filter.

Parametrics

P540A06 absolute maximum ratings: (1)Center Frequency(fo): 5400MHz; (2)Passband Width: fo +/- 500MHz; (3)Insertion Loss: 1.5dB max.; (4)V.S.W.R. (Unbalance Port): 2.2dB Max.; (5)Attenuation1 (at DC-2.5GHz): 25dB min; (6)Attenuation2 (at 9.8-11.8GHz): 20dB min; (7)Attenuation3 (at 14.7-17.7GHz): 15dB min; (8)Amplitude balance: 1.5dB max; (9)Impedance ratio Ohm: 50:50 or 50:100.

Features

P540A06 feature: BPF with Balun for W-LAN.

Diagrams

P540A06 block diagram
