Product Summary

The MG75G2DL1 is a transistor module designed for use in various types of motor control and other high power switching applications and consist of insulated type darlington transistors. The electrodes are fully isolated from heat sink. Single ended electrode construction is used to greatly simplify mounting.

Parametrics

MG75G2DL1 absolute maximum ratings: (1)Max.Tj: 150℃; (2)Storage temperature range: -40 to 125℃; (3)Isolation voltage: 2500V.

Features

MG75G2DL1 features: (1)Electrodes are isolated from the heat sink; (2)High DC current gain; (3)Low saturation voltage; (4)Wide safe operating area.

Diagrams

MG75G2DL1 block diagram
