Product Summary

The FZ900R12KF4 is an IGBT module. The applications of it are High Power Switching, A.C. Motor Controls, D.C. Motor Controls, Uninterruptible Power Supply.

Parametrics

FZ900R12KF4 absolute maximum ratings: (1)Circuits Io: 25 to 3300A; (2)Voltage VRRM: 600 to 4000V; (3)Viso: 2500V.

Features

FZ900R12KF4 features: (1)Square RBSOA; (2)Low Saturation Voltage; (3)Less Total Power Dissipation; (4)Improved FWD Characteristic; (5)Minimized Internal Stray Inductance; (6)Overcurrent Limiting Function.

Diagrams

FZ900R12KF4 block diagram
