Product Summary

The FP50R12KS4C is an IGBT-Module.

Parametrics

FP50R12KS4C absolute maximum ratings: (1)repetitive peak reverse voltage: 1600 V; (2)maximum RMS current at Rectifier output: t.b.d. A; (3)DC forward current: 50 A at TC = 80℃; (4)surge forward current: 500 A at tP = 10 ms, Tvj = 25℃, 400 A at tP = 10 ms, Tvj = 150℃; (5)I2t - value: 800 A2s at tP = 10 ms, Tvj = 150℃, 1250 A2s at tP = 10 ms, Tvj = 25℃.

Features

FP50R12KS4C features: (1)internal insulation: Al2O3; (2)comperative tracking index: 225; (3)mounting torque: ±10%; (4)weight: 300 g.

Diagrams

FP50R12KS4C block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FP50R12KS4C
FP50R12KS4C

Infineon Technologies

IGBT Transistors 1200V 50A PIM

Data Sheet

0-6: $105.23
6-10: $94.70
