Product Summary

The CM150TU-12H is an IGBT module. The applications of it are UPS, NC machine, AC-Drive control, Servo, Welders.

Parametrics

CM150TU-12H absolute maximum ratings: (1)VCES: 1200V; (2)VGES: ±20V; (3)IC: 150A; (4)ICM: 300A; (5)IC: 150A; (6)Collector dissipation: 600W; (7)Storage temperature: -40 to 125℃.

Features

CM150TU-12H features: (1)IC: 150A; (2)VCES:1200V; (3)Insulated type; (4)2-elements in a pack.

Diagrams

CM150TU-12H block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CM150TU-12H
CM150TU-12H


IGBT MOD 6PAC 600V 150A U SER

Data Sheet

0-1: $150.49
