Product Summary

The BSM300GB60DLC is an IGBT module.

Parametrics

BSM300GB60DLC absolute maximum ratings: (1)collector emitter voltage, VCES: 3300V; (2)DC collector current, IC: 1300A; (3)repetitive peak collector current, ICRM: 1600A; (4)total power dissipation, Ptot: 9.6kW; (5)gate-emitter peak voltage, VGES: ±20V.

Features

BSM300GB60DLC features: (1)forward voltage, VF: 2.8V; (2)peak reverse recovery current, IRM: 1100A; (3)recovered charge, Qr: 500μC.

Diagrams

BSM300GB60DLC block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BSM300GB60DLC
BSM300GB60DLC

Infineon Technologies

IGBT Modules 600V 300A DUAL

Data Sheet

0-6: $84.13
6-10: $75.72
