Product Summary

The PNOZ X2.1 is an Emergency stop relay and safety gate monitor in accordance with VDE 0113-1 Part 1, 11/98 and EN 60204-1, 12/97.

Parametrics

PNOZ X2.1 absolute maximum ratings: (1)Supply Voltage: AC24 V, DC24 V; (2)Tolerance: 85 to 110 %; (3)Power Consumption: Approx. 2 W/2 VA; (4)Voltage and Current at the Input and Reset Circuits and Feedback Control Loop: 24 VDC/25 mA.

Features

PNOZ X2.1 features: (1)Dual-channel operation which detects shorts across the input contacts; (2)Supply voltage: 24 VAC/DC; (3)monitored manual reset only.

Diagrams

PNOZ X2.1 block diagram
