K8AB-TH12S

K8AB-TH12S, Temperature Monitoring Relay, 100-240VAC, 50/60 Hz, 24 VDC, 2 W, 1 kΩ, Omron Electronics LLC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $131.00~197.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	197.00 / Piece
10 ~ 15 :	164.00 / Piece
15 ~ 20 :	131.00 / Piece

PartNumber:: K8AB-TH12S

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-29

From Other Seller

Part Number:K8AB-TH12S
US $131.00 - 197.00
Quantity:

piece

Product Summary

The K8AB-TH12S is a Temperature Monitoring Relay.

Parametrics

K8AB-TH12S absolute maximum ratings: (1)Power supply voltage: 100 to 240 VAC 50/60 Hz, 24 VAC 50/60 Hz or 24 VDC; (2)Allowable voltage range: 85% to 110% of power supply voltage; (3)Power consumption: 5 VA max. 2 W max. (24 VDC), 4 VA max. (24 VAC); (4)Contact input: ON 1 kΩ max., OFF 100 kΩ min.; (5)Non-contact input: ON residual voltage 1.5 V max., OFF leakage current 0.1 mA max.; (6)Leakage current: Approx. 10 mA; (7)Indicators Power (PWR): Green LED, Relay output (ALM): Red LED; (8)Ambient operating temperature: -10 to 55℃ (with no condensation or icing); (9)Ambient operating humidity Relative humidity: 25% to 85%; (10)Storage temperature: -25 to 65℃ (with no condensation or icing).

Features

K8AB-TH12S features: (1)Excessive temperature increases can be prevented and abnormal temperatures can be monitored; (2)Temperature monitoring in slim design with a width of just 22.5 mm; (3)Simple function settings using DIP switch; (4)Universal-input support for thermocouple or Pt100 sensor input; (5)Selectable output relay: Non-fail safe/fail safe; (6)Alarm status identification with LED indicator.
