JS1-5V

JS1-5V, 1a/1c 10A cubic type power relay,360mW, 250VAC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.57 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 20 :	0.57 / Piece
20 ~ 60 :	0.49 / Piece
60 ~ 80 :	0.40 / Piece

PartNumber:: JS1-5V

Brand:: Panasonic Semiconductor - Panasonic | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-08

From Other Seller

Part Number:JS1-5V
US $0.40 - 0.57
Quantity:

piece

Product Summary

The JS1-5V is one kind of 1a/1c 10A cubic type power relay. It can be used in (1)Home appliances: Air conditioner, heater, etc.; (2)Office machines: PPC, facsimile, etc.; (3)Vending machines.

Parametrics

JS1-5V absolute maximum ratings: (1)Contact resistance (initial): Max. 100 mΩ (By voltage drop 6 V DC 1A); (2)Max. switching voltage: 250V AC, 100V DC (0.5A); (3)Max. switching current: 10A (AC), 5A (DC); (4)Nominal operating power: 360mW; (5)Min. switching capacity: 100mA, 5V DC; (6)Max. operating speed: 20 times/min. (at nominal switching capacity).

Features

JS1-5V features: (1)Miniature size with universal terminal footprint; (2)High contact capacity: 10 A; (3)TV-5 type available (Standard type) 1 Form A type - TV-5 and 1 Form C type - TV-5 (N.O. side only); (4)VDE, TUV also approved; (5)Sealed construction for automatic cleaning (Standard type); (6)Class B and F coil insulation type also available.; (7)EN60335-1 GWT compliant (Tested by VDE) type available; (8)Surge voltage 6 kV type also available.
