Product Summary

The G7SA-4A2B is a slim relay.

Parametrics

G7SA-4A2B absolute maximum ratings: (1)Rated load: 6 A at 250 VAC, 6 A at 30 VDC; (2)Rated carry current: 6 A; (3)Max. switching voltage: 250 VAC, 125 VDC; (4)Max. switching current: 6 A; (5)Max. switching capacity (reference value): 1,500 VA, 180 W.

Features

G7SA-4A2B features: (1)EN50205 Class A, approved by VDE; (2)Ideal for use in safety circuits in production machinery; (3)Four-pole and six-pole Relays are available; (4)The Relays terminal arrangement simplifies PWB pattern design; (5)Reinforced insulation between inputs and outputs. Reinforced insulation between some poles; (6)UL, CSA approval.

Diagrams

G7SA-4A2B pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
G7SA-4A2B DC24
G7SA-4A2B DC24

RELAY SAFETY 6PST 6A 24V
Data Sheet
0-1: $36.11
1-25: $32.51
25-50: $28.89
50-100: $26.00
100-250: $24.56
250-500: $21.67
500-1000: $19.50
G7SA-4A2B-DC24
G7SA-4A2B-DC24
Omron Electronics
Safety Relays 24DC 4PST-NO DPST-NC 6 CONTACTS
Data Sheet
0-1: $30.86
1-10: $28.46
10-25: $26.87
25-50: $25.69
