G3PE-525B

G3PE-525B, single-phase solid state relay, 1.6 V, 1 ms, 100 M

Rated 5 Rating 5 | reviews | Write a review

Price:: US $131.00~197.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 20 :	197.00 / Piece
20 ~ 30 :	164.00 / Piece
30 ~ 40 :	131.00 / Piece

PartNumber:: G3PE-525B

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-15

From Other Seller

Part Number:G3PE-525B
US $131.00 - 197.00
Quantity:

piece

Product Summary

The G3PE-525B is a single-phase solid state relay.

Parametrics

G3PE-525B absolute maximum ratings: (1)Operate time: 1/2 of load power source cycle + 1 ms max.; (2)Release time: 1/2 of load power source cycle + 1 ms. max.; (3)Output ON voltage drop: 1.6 V (RMS) max.; (4)Leakage current: 10 mA max.; (5)Insulation resistance: 100 MΩ min. (500 VDC); (6)Dielectric strength: 2,500 VAC, 50/60 Hz for 1 min; (7)Vibration resistance: 10 to 55 to10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude) (Mounted to DIN track); (8)Ambient temperature: Operating: -30°C to 100°C (with no icing or condensation).

Features

G3PE-525B features: (1)Snubber circuit provides excellent short-term surge absorption; (2)15A and 25A models have slim 22.5mm width; (3)Zero cross or fast turn on models; (4)DIN track or panel mounting possible; (5)LED indicator standard on all single phase models; (6)UL, CSA and TUV approved; (7)RoHS compliant.
