Product Summary

The G3NA-D210B is a solid-state relay.

Parametrics

G3NA-D210B absolute maximum ratings: (1)Rated voltage: 100 to 240 VAC; (2)Operating voltage: 75 to 264 VAC; (3)Must operate voltage: 75 VAC max.; (4)Inrush current: 20 A (10 ms); (5)Ambient temperature Operating: -30°C to 80°C, Storage: -30°C to 100°C.

Features

G3NA-D210B features: (1)All models feature the same compact dimensions to provide a uniform mounting pitch; (2)Built-in varistor effectively absorb external surges; (3)Operation indicator (red LED)enables monitoring operation; (4)Protective cover for greater safety; (5)Standard models approved by UL/CSA and -UTU models by VDE (TUV).

Diagrams

G3NA-D210B pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
G3NA-D210B-AC100-240
G3NA-D210B-AC100-240
Omron Industrial
Solid State Relays 100-240VAC/200DC 10A
Data Sheet
0-1: $31.58
1-25: $29.63
25-50: $27.70
50-100: $26.02
G3NA-D210B-DC5-24
G3NA-D210B-DC5-24
Omron Industrial
Solid State Relays 5-24VDC/200VDC 10A
Data Sheet
0-1: $22.57
1-25: $20.27
25-50: $19.43
50-100: $18.65
G3NA-D210B-UTU DC5-24
G3NA-D210B-UTU DC5-24
Omron Industrial
Solid State Relays SSR 10A DC LOAD TUV MARK
Data Sheet
0-1: $34.16
