DF2E-DC5V

DF2E-DC5V, highly sensitive DIP miniature relay, 3 ms, 50 mΩ, 5 ms, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.64~0.96 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 20 :	0.96 / Piece
20 ~ 60 :	0.80 / Piece
60 ~ 80 :	0.64 / Piece

PartNumber:: DF2E-DC5V

Brand:: Panasonic Semiconductor - Panasonic | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-15

From Other Seller

Part Number:DF2E-DC5V
US $0.64 - 0.96
Quantity:

piece

Product Summary

The DF2E-DC5V is designed as a highly sensitive DIP miniature relay. And it can be used in (1)Office and industrial electronic devices; (2)Terminal devices of information processing equipment, such as printer, data recorder; (3)Office equipment (copier, facsimile); (4)Measuring instruments; (5)NC machines, temperature controllers and programmable logic controllers.

Parametrics

DF2E-DC5V absolute maximum ratings: (1)Arrangement: 2 Form C; (2)Initial contact resistance: 50 mΩ; (3)Contact material: gold-clad silver; (4)Temperature rise: Max. 65°C; (5)Operate time (at nominal voltage): Max. 5 ms (Approx. 2.5 ms); (6)Release time: Max. 3 ms (Approx. 1 ms).

Features

DF2E-DC5V features: (1)Smaller than most of 2 form C relays header area: 80% of DS2 relay, and cubic measure: 57% of DS2 relay; (2)high sensitivity - 100mW nominal power for 1 coil latching type; (3)DIP - matching 14 pin IC socket.
