Product Summary

The TMP275AID is a 0.5℃ accurate, two-wire, serial output temperature sensor available in the MSOP-8 package. The TMP275AID is capable of reading temperatures with a resolution of 0.0625℃. The TMP275AID is SMBus-compatible and allows up to eight devices on one bus. It is ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental, industrial, and instrumentation applications. The applications of the TMP275AID are power-supply temperature monitoring, computer peripheral thermal protection, notebook computers, cell phones, battery management, office machines, thermostat controls, environmental monitoring and hvac and electromechanical device temperature.

Parametrics

TMP275AID absolute maximum ratings: (1)Power Supply, V+: 7.0V; (2)Input Voltage: -0.5V to 7.0V; (3)Input Current: 10mA; (4)Operating Temperature Range: -55 to +127℃; (5)Storage Temperature Range: -60℃ to +130℃; (6)Junction Temperature (TJ max): +150℃; (7)ESD Rating: Human Body Model (HBM): 4000V; Charged Device Model (CDM): 1000V; Machine Model (MM): 300V.

Features

TMP275AID features: (1)8 addresses; (2)digital output: Two-Wire Serial Interface; (3)resolution: 9- to 12-Bits, User-Selectable; (4)accuracy: ±0.5℃ (max) from +10 to +85℃; ±0.75℃ (max) from +0 to +100℃; (5)low quiescent current: 50μA, 0.1μA Standby; (6)wide supply range: 2.7V to 5.5V; (7)small MSOP-8 package.

Diagrams

TMP275AID block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TMP275AID
TMP275AID

Texas Instruments

Board Mount Temperature Sensors 0.5C Dig Out Temp Sensor

Data Sheet

0-1: $1.55
1-10: $1.39
10-25: $1.24
25-50: $1.17
TMP275AIDG4
TMP275AIDG4

Texas Instruments

Board Mount Temperature Sensors 0.5C Dig Out Temp Sensor

Data Sheet

0-1: $1.55
1-10: $1.39
10-25: $1.24
25-50: $1.17
TMP275AIDGKTG4
TMP275AIDGKTG4

Texas Instruments

Board Mount Temperature Sensors 0.5C Digital Out

Data Sheet

0-1: $1.49
1-10: $1.33
10-25: $1.19
25-100: $0.80
100-250: $0.79
TMP275AIDGKT
TMP275AIDGKT

Texas Instruments

Board Mount Temperature Sensors 0.5C Digital Out

Data Sheet

0-1: $1.49
1-10: $1.33
10-25: $1.19
25-100: $0.80
100-250: $0.79
TMP275AIDGKR
TMP275AIDGKR

Texas Instruments

Board Mount Temperature Sensors 0.5C Digital Out

Data Sheet

0-2020: $0.64
2020-2500: $0.62
TMP275AIDGKRG4
TMP275AIDGKRG4

Texas Instruments

Board Mount Temperature Sensors 0.5C Digital Out

Data Sheet

0-2020: $0.64
2020-2500: $0.62
TMP275AIDRG4
TMP275AIDRG4

Texas Instruments

Board Mount Temperature Sensors 0.5C Dig Out Temp Sensor

Data Sheet

0-2020: $0.64
2020-2500: $0.62
TMP275AIDR
TMP275AIDR

Texas Instruments

Board Mount Temperature Sensors 0.5C Dig Out Temp Sensor

Data Sheet

0-2020: $0.64
2020-2500: $0.62
