Product Summary

The EL640.480-AM1 is an ICEBrite EL VGA Display. It offers designers an affordable and easily-implemented path to incorporate flat panel solutions to meet display requirements.

Parametrics

EL640.480-AM1 absolute maximum ratings: (1)Video logic high voltage: 3.7 V to 5.0 V; (2)Video logic low voltage: 0 V to 0.9 V; (3)Video logic input current: –10 μA to +10 μA.

Features

EL640.480-AM1 features: (1)Excellent viewing characteristics; (2)High brightness and contrast; (3)Wide viewing angle; (4)Long life; (5)Extreme ruggedness; (6)Designed for low EMI; (7)Fast response time; (8)Lower power.

Diagrams

EL640.480-AM1 diagram
