Product Summary
The 78L12A is a rotary backlock connector. The 78L12A of fixed-voltage monolithic integrated-circuit voltage regulator is designed for a wide range of applications. The applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, the 78L12A can be used with power-pass elements to make high-current voltage regulator. The regulator can deliver up to 100 mA of output current. The internal limiting and termal shutdown features of the regulator makes the 78L05A essentially immune to overload. When used as a replacement for a Zener diode-resistor combination, an effective improvement in output impedance can be obtained together with lower-bias current.
Parametrics
78L12A absolute maximum ratings: (1)Input voltage: 30V; (2)Operating free-air, case, or virtual junction temperature range: 0 to 150℃; (3)Storage temperature range: -65 to 150℃; (4)Lead temperature 1.6 mm (1/16 inch) from case for 10 seconds: 260℃.
Features
78L12A features: (1)3-Terminal Regulators; (2)Output Current Up to 100 mA; (3)No External Components; (4)Internal Thermal Overload Protection; (5)Internal Short-Circuit Limiting.
