74HC14D

74HC14D, Hex inverting Schmitt trigger, 14SOIC, 7V, 20mA, NXP Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~1.00

PartNumber:: 74HC14D

Brand:: Philips Electronics India Limited - PHILIPS | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jack's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-14

From Other Seller

Part Number:74HC14D
US $0.10 - 1.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74HC14D is a Hex inverting schmitt trigger. The 74HC14D is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL). The device is specified in compliance with JEDEC standard no. 7A. The 74HC14D provides six inverting buffers with Schmitt-trigger action. It is capable of transforming slowly changing input signals into sharply defined, jitter-free output signals. The applications of 74HC14D include wave and pulse shapers, astable multivibrators, monostable multivibrators.

Parametrics

74HC14D absolute maximum ratings: (1)Supply voltage: -0.5 to +7 V; (2)Input diode current: when VI < -0.5 V or VI > VCC + 0.5 V, ±20 mA; (3)Output diode current: VO < -0.5 V or VO > VCC + 0.5 V, ±20 mA; (4)Output source or sink current: -0.5 V < VO < VCC + 0.5 V, ±25 mA; (5)VCC or GND current: 50 mA; (6)Storage temperature: -65~ +150 ℃; (7)Power dissipation: -40 to +125 ℃; (8)DIP14 packages: 750 mW; (9)Other packages: -500 mW.

Features

74HC14D features: (1)Complies with JEDEC standard no. 7A; (2)ESD protection: HBM EIA/JESD22-A114-A exceeds 2000 V; MM EIA/JESD22-A115-A exceeds 200 V; (3)Specified from -40 to +85℃ and -40 to +125℃.
