74F640PC

octal bus transceiver, DIP-20, -0.5V to +7.0V, -30 mA to +5.0 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.50~3.20

PartNumber:: 74F640PC

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 96+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jack's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-17

From Other Seller

Part Number:74F640PC
US $2.50 - 3.20
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74F640PC is an octal bus transceiver designed for asynchronous two-way data flow between the A and B busses. Both busses are capable of sinking 64 mA, have 3- STATE outputs, and a common output enable pin. The direction of data flow is determined by the transmit/receive (T/R) input. The 74F640PC is an inverting option of the 74F645.

Parametrics

74F640PC absolute maximum ratings: (1)Storage Temperature: -65 to +150℃; (2)Ambient Temperature under Bias: -55 to +125℃; (3)Junction Temperature under Bias: -55 to +150℃; (4)VCC Pin Potential to Ground Pin: -0.5V to +7.0V; (5)Input Voltag: -0.5V to +7.0V; (6)Input Current: -30 mA to +5.0 mA.

Features

74F640PC features: (1)Designed for asynchronous two-way data flow between busses; (2)Outputs sink 64 mA; (3)Transmit/receive (T/R) input controls the direction of data flow; (4)74F640 is an inverting option of the 74F645.
