Product Summary
The E5CN-RTU is a basic-type digital temperature controller.
Parametrics
E5CN-RTU absolute maximum ratings: (1)Alarm output: SPST-NO, 250 VAC, 1 A (resistive load), electrical life: 100,000 operations, minimum applicable load: 1 V, 1 mA; (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Input impedance Current input: 150 Ω max., Voltage input: 1 MΩ min. (Use a 1:1 connection when connecting the ES2-HB.); (4)Control method: ON/OFF control or 2-PID control (with auto-tuning): 50 A; (5)External power supply for ES1B 12 VDC ±10%, 20 mA, short-circuit protection circuit provided; (6)Ambient operating temperature -10 to 55°C (with no condensation or icing), for 3-year warranty: -10 to 50°C; (7)Ambient operating humidity 25% to 85%; (8)Storage temperature: -25 to 65°C (with no condensation or icing).
Features
E5CN-RTU features: (1)Controllers now available with analog inputs; (2)Faster sampling at 250 ms; (3)Transfer output provided for easy output to recorders; (4)Voltage outputs (to drive SSRs) for both heating and cooling control. Can be used for alarms to provide three alarm outputs.; (5)Models available with three-phase heater burnout detection and SSR fault detection; (6)Easy setting with 11-segment displays; (7)Connect to either a thermocouple or platinum resistance thermometer with the same model; (8)Easily see the status from a distance with PV display with threecolor switching function; (9)Setting protection indicator informs operator when protection is enabled; (10)Manual output provided; (11)Controller available with long-life relay output (available soon).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 E5CN-RTU AC100-240 |
Omron Industrial |
Controllers Multi-Sensor Input 1 16 Din TC |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
E5CN-C1LU AC100-240 |
|
TEMP CONTROLLER DGTL 1/16 DIN |
Data Sheet |
|
|
||||||||||||
|
E5CN-C1TDU AC/DC24 |
|
TEMP CONTROLLER DGTL 1/16 DIN |
Data Sheet |
|
|
||||||||||||
|
E5CN-C1TU AC100-240 |
|
TEMP CONTROLLER DGTL 1/16 DIN |
Data Sheet |
|
|
||||||||||||
|
E5CN-C2LU AC100-240 |
|
TEMP CONTROLLER DGTL 1/16 DIN |
Data Sheet |
|
|
||||||||||||
|
E5CN-C2ML-500 AC100-240 |
|
TEMP CONTROLLER DGTL 1/16 DIN |
Data Sheet |
|
|
||||||||||||
|
E5CN-C2MLD-500 AC/DC24 |
Omron Industrial |
Controllers Analog Input 1/16 Di n TC New08 |
Data Sheet |
|
|
||||||||||||
