Product Summary
The H3CR-F8 is a solid-state multi-functional timer.
Parametrics
H3CR-F8 absolute maximum ratings: (1)Impulse withstand voltage: 3 kV; (2)Noise immunity: ±1.5 kV; (3)Static immunity Malfunction: 8 kV; (4)Destruction: 15 kV; (5)Vibration resistance Destruction: 10 to 55 Hz; (6)Malfunction: 10 to 55 Hz; (7)Shock resistance Destruction: 1,000 m/s2 3 times each in 6 directions; (8)Malfunction: 100 m/s2 3 times each in 6 directions; (9)Ambient temperature Operating: -10°C to 55°C (with no icing); (10)Storage: -25°C to 65°C (with no icing).
Features
H3CR-F8 features: (1)A wider power supply range reduces the number of timer models kept in stock; (2)A wide range of applications through six or four operating modes; (3)Reduced power consumption; (4)Enables easy sequence checks through instantaneous outputs for a zero set value at any time range; (5)Length, when panel-mounted with a Socket, of 80 mm or less; (6)Time Setting Rings enable consistent settings and limit the setting range; (7)Panel Covers enable various panel designs; (8)PNP input models available; (9)Rich variety of inputs: Start, reset, and gate functions (11-pin models and -AP models).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 H3CR-F8 AC/DC24 |
|
RELAY REPEAT CYCLE ANLG 30HRS |
Data Sheet |
|
|
||||||||||||||
 |
H3CR-F8 DC12 |
Omron Industrial |
Controllers Timer Repeat Cycle |
Data Sheet |
|
|
||||||||||||||
|
H3CR-F8-300 AC/DC24 |
Omron Industrial |
Controllers TIMER REPEAT CYCLE |
Data Sheet |
|
|
||||||||||||||
|
H3CR-F8-300 AC100-240 |
|
RELAY REPEAT CYCLE ANALOG 300HRS |
Data Sheet |
|
|
||||||||||||||
|
H3CR-F8-300 DC12 |
Omron Industrial |
Controllers TIMER REPEAT CYCLE |
Data Sheet |
|
|
||||||||||||||
 |
H3CR-F8-300-AC100/240 |
Omron Industrial |
Stopwatches & Timers REPEAT CYCLE TIMER |
Data Sheet |
|
|
||||||||||||||
|
H3CR-F8-AC100-240 |
Omron Industrial |
Stopwatches & Timers REPEAT CYCLE TIMER |
Data Sheet |
|
|
||||||||||||||
|
H3CR-F8N AC/DC24 |
Omron Industrial |
Controllers Timer Repeat Cycle |
Data Sheet |
|
|
||||||||||||||
