Product Summary
The E5AZ-R3 is a basic-type digital temperature controller.
Parametrics
E5AZ-R3 absolute maximum ratings: (1)Power consumption: 100 to 240 VAC: 10 VA 24 VAC/VDC: 5.5 VA (24 VAC)/4 W (24 VDC); (2)Input impedance Current input: 150 Ω max.; (3)Current output: 4 to 20 mA; (4)Ambient operating temperature: -10 to 55°C (with no condensation or icing), for 3-year warranty: -10 to 50°C; (5)Ambient operating humidity: 25% to 85%; (6)Storage temperature: -25 to 65°C (with no condensation or icing).
Features
E5AZ-R3 features: (1)Indication Accuracy; (2)A PV/SV-status display function can be set to automatically alternate between displaying the status of the Temperature; (3)Preventive maintenance for relays in the Temperature Controller using a Control Output ON/OFF Counter; (4)Three-level display that simultaneously displays the PV, SV, and MV; (5)One-touch operation with PF Key that can be assigned to auto/ manual, RUN/STOP, or other functions.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 E5AZ-R3HML AC100-240 |
|
MEXLA TC RLY 3 ALM |
Data Sheet |
|
|
||||||
|
E5AZ-R3HMLD AC/DC24 |
|
MEXLA TC RLY OUT 3 ALM 24VDC |
Data Sheet |
|
|
||||||
|
E5AZ-R3HMT AC100-240 |
|
MEXLA TC RLY OUT 3 ALM |
Data Sheet |
|
|
||||||
|
E5AZ-R3HMTD AC/DC24 |
|
MEXLA TC RLY OUT 3 ALM |
Data Sheet |
|
|
||||||
|
E5AZ-R3MT AC100-240 |
|
MEXLA TC RLY OUT 3 ALM |
Data Sheet |
|
|
||||||
|
E5AZ-R3MTD AC/DC24 |
|
MEXLA TC RLY OUT 3 ALM |
Data Sheet |
|
|
||||||
|
E5AZ-R3T AC100-240 |
|
MEXLA TC RLY OUT 3 ALM |
Data Sheet |
|
|
||||||
