Product Summary

The SKM50GAL123D is an IGBT module. It is suitable for three phase ivnerter drivers and switching.

Parametrics

SKM50GAL123D absolute maximum ratings: (1)VCES: 1200V; (2)VCGR: 1200V; (3)IC: 50A; (4)ICM: 100A; (5)VGES: ±20V; (6)Ptot: 310W; (7)Visol: 2500V.

Features

SKM50GAL123D features: (1)MOS input (voltage controlled); (2)N channel, homogeneous Si; (3)low inductance case; (4)very low tail current with low temperature dependence; (5)high short circuit capability, self limiting to 6Icnom; (6)latch-up free; (7)fast & soft inverse CAL diodes; (8)isolated copper baseplate using DCB direct copper bonding technology; (9)large clearance and creepage distances.

Diagrams

SKM50GAL123D block diagram
