SKM100GB173D

SKM100GB173D, IGBT module, 1700V, 100A, Semikron International

Rated 5 Rating 5 | reviews | Write a review

Price:: US $82.00~89.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 25 :	89.00 / Piece
27 ~ 35 :	86.00 / Piece
38 ~ 48 :	82.00 / Piece

PartNumber:: SKM100GB173D

Brand:: Semikron International - SEMIKRON | D/C: 07+

Availability:: Supply Ability: 300/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-28

From Other Seller

Part Number:SKM100GB173D
US $82.00 - 89.00
SKM100GB173D Trans IGBT Module N-CH 1.7KV 110A

US $8.40 - 12.40 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SKM100GB173D is an IGBT module. The applications of the SKM100GB173D include AC inverter drives on mains 575-750VAC, DC bus voltage 750-1200VDC, public transport(auxiliary syst.), switching (not for linear use).

Parametrics

SKM100GB173D absolute maximum ratings: (1)VCES: 1700 V; (2)IC: 110 (75) A at Tc=25 (80) ℃; (3)ICRM: 150 A at tp=1 ms; (4)VGES: ± 20 V; (5)Tvj,(Tstg): -40 to +150 ℃ at TOPERATION ≤ Tstg; (6)Visol: 2500 V at AC, 1 min; (7)IF: 80 (50) A at Tc=25 (80) ℃; (8)IFRM: 150 A at tp=1 ms; (9)IFSM: 720 A at tp=10 ms; sin,;Tj=150 ℃.

Features

SKM100GB173D features: (1)N channel,homogeneous Si; (2)very low tail current with low temperature dependence; (3)high short circuit capability, self limiting to 6×Icnom; (4)latch-up free; (5)fast & soft inverse CAL diodes; (6)isolated copper baseplate using DCB direct copper bonding technology; (7)large clearance (10 mm) and creepage distances (20 mm).
